Technical Specifications
Bearing No. | Dimensions(mm) | Rated Load(KN) | Mass(kg) | |||||
Old Code | New Code | d | D | B | r | Cr | Cor | |
3056212M | 3212M | 60 | 110 | 36.5 | 1.5 | 83.5 | 72.5 | 1.55 |
3056213M | 3213M | 65 | 120 | 38.1 | 1.5 | 87.5 | 79.5 | 1.78 |
3056214M | 3214M | 70 | 125 | 39.7 | 1.5 | 90 | 80.5 | 1.9 |
3056215M | 3215M | 75 | 130 | 41.3 | 1.5 | 106 | 95.5 | 2.15 |
3056216M | 3216M | 80 | 140 | 44.4 | 2 | 112 | 106 | 2.7 |
3056217M | 3217M | 85 | 150 | 49.2 | 2 | 140 | 129 | 3.5 |
3056218M | 3218M | 90 | 160 | 52.4 | 2 | 153 | 142 | 4.18 |
3056219M | 3219M | 95 | 170 | 55.6 | 2.1 | 163 | 184 | 5.1 |
3056220M | 3220M | 100 | 180 | 60.3 | 2.1 | 210 | 240 | 6.14 |
3056221M | 3221M | 105 | 190 | 65.1 | 2.5 | 210 | 240 | 7.4 |
3056222M | 3222M | 110 | 200 | 69.8 | 2.5 | 218 | 245 | 9.2 |
3056224M | 3224M | 120 | 215 | 76 | 3 | 251 | 291.5 | 11.1 |
3056226M | 3226M | 130 | 230 | 80 | 3.5 | 259.5 | 314.9 | 13.3 |
3056228M | 3228M | 140 | 250 | 88 | 3.5 | 304.5 | 391.3 | 15.2 |
3056308M | 3308M | 40 | 90 | 36.5 | 1.5 | 60.5 | 44 | 1.01 |
3056309M | 3309M | 45 | 100 | 39.7 | 1.5 | 72.5 | 54 | 1.41 |
3056310M | 3310M | 50 | 110 | 44.4 | 2 | 85.5 | 65 | 1.96 |
3056311M | 3311M | 55 | 120 | 49.2 | 2 | 106 | 82 | 2.68 |
3056312M | 3312M | 60 | 130 | 54 | 2.1 | 122 | 96 | 3.25 |
3056313M | 3313M | 65 | 140 | 58.7 | 2.1 | 138 | 109 | 4.18 |
3056314M | 3314M | 70 | 150 | 63.5 | 2.5 | 155 | 125 | 5.2 |
3056315M | 3315M | 75 | 160 | 68.3 | 2.5 | 168 | 141 | 5.85 |
3056316M | 3316M | 80 | 170 | 68.3 | 3 | 175 | 151 | 7.75 |
3056317M | 3317M | 85 | 180 | 73 | 3 | 196 | 240 | 8.3 |
3056318M | 3318M | 90 | 190 | 73 | 3 | 225 | 266 | 9.02 |
3056319M | 3319M | 95 | 200 | 77.8 | 3.5 | 269 | 294 | 11.16 |
3056320M | 3320M | 100 | 215 | 82.6 | 3.5 | 309 | 359 | 14.2 |
3056321M | 3321M | 105 | 225 | 87.3 | 3.5 | 309 | 360 | 16.35 |
3056322M | 3322M | 110 | 240 | 92.1 | 3.5 | 329 | 403 | 19.8 |
3056324M | 3324M | 120 | 260 | 106 | 3.5 | 397.9 | 493.3 | 25.4 |
3056326M | 3326M | 130 | 280 | 112 | 4 | 443.95 | 584.9 | 27.1 |
3056328M | 3328M | 140 | 300 | 118 | 4 | 467.3 | 676.3 | 33.4 |
LEAVE US A MESSAGE
If you have any questions, please fill out the form to contact us, and our customer service will reply to you within 24 hours!
Suffixes |
|
Sealing Types |
|
2Z |
Metal shield (non-contact sealing) on both sides |
2RS |
One lip rubber metal seal on both sides |
2RS1 |
One lip rubber metal seal on both sides |
2S |
One lip rubber metal seal (on both sides) |
2F |
One lip rubber metal seal + flinger, on both sides |
2T |
Three lip seal on both sides |
T |
Outer ring with stopping pin |
2TC |
Three lip seal on both sides+ metal cover |
2TB |
Three lip seal + metal shield, on both sides |
TDT |
Three lip seal at one side, double three lip seal on the other side |
FS |
Sealing with one lip seal and a protective metal ring at one side and one lip seal on the other side |
TBS |
Sealing with three lip seal and a protective metal ring at one side and one lip seal on the other side |
TBT |
Sealing with three lip seal and a protective metal ring at one side and three lip seal on the other side |
2P |
Five lip seal on both sides |
2PB |
Five lip seal and metal shield, on both sides |
2PC |
Five lip seal on both sides + metal cover |
P |
Triple lip seal on one side, cylindrical surface of outer ring |
PP |
Triple lip seal, cylindrical surface of outer ring |
PB |
Triple lip seal on one side, spherical surface of outer ring |
PPB |
Triple lip seal, spherical surface of outer ring |
RR |
One lip seal cylindrical surface of outer ring |
RRB |
One lip seal spherical surface of outer ring |
KPP |
Triple lip seal cylindrical surface of outer ring |
KPPB |
Triple lip seal spherical surface of outer ring |
KR |
One lip seal on one side, cylindrical surface of outer ring |
KRR |
One lip seal, cylindrical surface of outer ring |
KRB |
One lip seal on one side, spherical surface |
KRRB |
One lip seal, spherical surface |
KRP |
One lip seal on one side and on the other side is triple lip seal |
